Excavator 31N9-10010 R335-7 hydraulic pump K3V180DT high quality
main pump
| Model NO. | K3V180DT |
| Description | Direct Factory Manufacture Hydraulic pump for R335-7 Excavator |
| Brand name | Belparts |
| Color | As the photo |
| Appliion | excavator |
| Condition | 100% brand new |
| Warranty | 1 Year |
| Packing | standard packing(fiberboad carton/wooden case)or as customzied |
| Payment term | T/T, PayPal,Alipay..etc. |
| Shipment | 1~7days after getting the payment,but not for the customzied item |
| Remark | Any more detailed information about the product,pls donot hestate
to inquiry with us.Also welcime to visitour company or factory if
you have free time.We will be appriciate for that. Thank you. |
List of spare parts
| # | Part No | Part Name | Qty. |
|---|
| * | 31N9-10010 | MAIN PUMP | 1 |
| *-1 | @ | FUEL INJECTION PIPE & NOZZLE | 1 |
| S012 | XJBN-00567 | BLOCK-CYLINDER | 2 |
| 111 | XJBN-00015 | SHAFT-DRIVE(F) | 1 |
| 113 | XJBN-00153 | SHAFT-DRIVE(R) | 1 |
| 114 | XJBN-00367 | COUPLING-SPLINE | 1 |
| 123 | XJBN-00017 | BEARING-ROLLER | 2 |
| 124 | XJBN-00018 | BEARING-NEEDLE | 2 |
| 127 | XJBN-00019 | SPACER-BEARING | 3 |
| S151 | XJBN-00566 | PISTON | 1 |
| S152 | XJBN-00565 | SHOE | 1 |
| 153 | XJBN-00020 | PLATE-SET | 2 |
| 156 | XJBN-00564 | BUSHING-SPHERICAL | 2 |
| 157 | XJBN-00541 | SPRING-CYLINDER | 18 |
| 211 | XJBN-00023 | PLATE-SHOE | 2 |
| S212 | XJBN-00012 | PLATE-SWASH | 1 |
| S214 | XJBN-00013 | BUSHING-TILTING | 1 |
| 251 | XJBN-00560 | SUPPORT-S.P. | 2 |
| 261 | XJBN-00025 | COVER(FR)-SEAL | 1 |
| 271 | XJBN-00026 | CASING-PUMP | 2 |
| 312 | XJBN-00027 | BLOCK-VALVE | 1 |
| S313 | XJBN-00557 | PLATE-VALVE(R) | 1 |
| S314 | XJBN-00556 | PLATE-VALVE(L) | 1 |
| 325 | XJBN-00380 | CASING-VALVE | 1 |
| 401 | XJBN-00028 | SCREW | 8 |
| 406 | XJBN-00355 | SCREW-HEX SOC HD | 4 |
| 466 | XJBN-00356 | PLUG | 2 |
| 468 | XJBN-00357 | PLUG | 3 |
| 490 | XJBN-00032 | PLUG | 30 |
| S531 | XJBN-00369 | PIN-TILTING | 1 |
| 532 | XJBN-00033 | PISTON-SERVO | 2 |
| 534 | XJBN-00034 | STOPPER(L) | 2 |
| 535 | XJBN-00035 | STOPPER(S) | 2 |
| 541 | XJBN-00036 | SEAT | 4 |
| 543 | XJBN-00037 | STOPPER 1 | 2 |
| 544 | XJBN-00039 | STOPPER 2 | 2 |
| 545 | XJBN-00359 | BALL-STEEL | 4 |
| S548 | XJBN-00360 | PIN-FEED BACK | 1 |
| K702 | XJBN-00040 | O-RING | 2 |
| K710 | XJBN-00041 | O-RING | 1 |
| K717 | XJBN-00042 | O-RING | 2 |
| K719 | XJBN-00043 | O-RING | 2 |
| K724 | XJBN-00044 | O-RING | 16 |
| K725 | XJBN-00362 | O-RING | 4 |
| K727 | XJBN-00283 | O-RING | 1 |
| K728 | XJBN-00363 | O-RING | 3 |
| K732 | XJBN-00047 | O-RING | 2 |
| K774 | XJBN-00906 | SEAL-OIL | 1 |
| K789 | XJBN-00049 | RING-BACK UP | 2 |
| K792 | XJBN-00050 | RING-BACK UP | 2 |
| 808 | XJBN-00364 | NUT | 4 |
| 824 | XJBN-00052 | RING-SNAP | 2 |
| 885 | XJBN-00053 | PIN-2 | 2 |
| 886 | XJBN-00365 | PIN-SPRING | 4 |
| 901 | XJBN-00055 | BOLT-EYE | 2 |
| 953 | XJBN-00654 | SCREW-SET | 2 |
| 954 | XJBN-00057 | SCREW-SET | 2 |
| 981 | XJBN-00391 | NAME PLATE | 1 |
| 983 | XJBN-00341 | PIN | 2 |
| *-2 | XJBN-00656 | REGULATOR | 1 |
| *-3 | XJBN-00655 | GEAR PUMP | 1 |
| 011 | XJBN-00563 | PISTON ASSY
SEE ILLUST | 18 |
| 013 | XJBN-00562 | CYLINDER ASSY-RH
SEE ILLUST | 1 |
| 014 | XJBN-00561 | CYLINDER ASSY-LH
SEE ILLUST | 1 |
| 030 | XJBN-00011 | SWASH PLATE ASSY
SEE ILLUST | 2 |
| 530 | XJBN-00371 | TILTING PIN ASSY
SEE ILLUST | 2 |
| K | XJBN-01108 | SEAL KIT-PUMP UNIT
SEE ILLUST | 1 |
