Belparts excavator main pump EC230B EC240 EC240B hydraulic pump SA 1142-00531 SA 8230-14650 VOE 14343114

Ask Lasest Price
Brand Name :	Belparts
Model Number :	EC230B EC240 EC240B
Price :	Negotiated price
Payment Terms :	T/T, trade assurance,PayPal
Supply Ability :	1000PCS
Delivery Time :	1~7 days

Add to Cart

Product Details
Company Profile

Belparts excavator main pump EC230B EC240 EC240B hydraulic pump SA 1142-00531 SA 8230-14650 VOE 14343114

Belparts excavator main pump EC230B EC240 EC240B hydraulic pump SA 1142-00531 SA 8230-14650 VOE 14343114

Appliion:Crawler excavator
Part name:Hydraulic Main Pump
Model:EC200 EC210 EC210B
Part number:SA 1142-00531 SA 8230-14650 VOE 14343114
Warranty:3-12 months
Payment term:T/T, Trade Assurance, Paypal and etc.
Brand:Hitachi or as require

Appliion	Crawler excavator
Part name	Hydraulic Main Pump
Model	EC200 EC210 EC210B
Part number	SA 1142-00531 SA 8230-14650 VOE 14343114
Warranty	3-12 months
Payment term	T/T, Trade Assurance, Paypal and etc.
Brand	Hitachi or as require

#	Part No	Part Name	Qty.	Price request
	SA 1142-00531	Pump more	1
1	SA 8230-14650	Piston	2
2	SA 14500003	Piston	9
3	SA 14500002	Seat	9
4	SA 8230-28580	Cylinder	1
5	SA 8230-28560	Block	1
6	SA 14500001	Plate	1
7	SA 8230-28590	Cylinder	1
8	SA 8230-28560	Block	1
9	SA 14500000	Plate	1
10	SA 8230-09800	Plate	2
11	SA 8230-30540	Plate	1
12	SA 14500012	Bushing	1
13	SA 7223-00450	Check valve more	2
14	SA 7223-00500	Seat	1
15	SA 7223-00520	Guard	1
16	SA 9676-73200	Ball more	1
17	SA 7223-00460	Check valve	2
18	SA 7223-00500	Seat	1
19	SA 7223-00540	Guard	1
20	SA 9676-73200	Ball more	1
21	SA 8230-09020	Valve more	1
22	SA 8230-09100	Shaft	1
23	SA 8230-09070	Shaft	1
24	SA 8230-09660	Coupling	1
25	SA 8230-26610	Roller Bearing more	2
26	SA 8230-26700	Needle Bearing more	2
27	SA 8230-14530	Spacer	4
28	SA 8230-09370	Plate	2
29	SA 8230-09680	Bushing more	2
30	SA 8230-09710	Spring	18
31	SA 8230-09670	Spacer	2
32	SA 8230-21920	Plate	2
33	SA 8230-08940	Support	2
34	SA 8230-09350	Cover	1
35	SA 8230-08930	Body	1
36	SA 8230-08980	Valve assembly	1
37	SA 8230-09690	Bolt	8
38	SA 9016-10804	Bolt more	4
39	SA 9415-11021	Plug more	3
40	SA 9415-11051	Plug more	4
41	SA 7242-11040	Plug more	21
42	SA 8230-09790	Pin	2
43	SA 8230-09320	Pin	1
44	SA 7223-00570	Pin	1
45	SA 8230-09250	Piston	2
46	SA 8230-09640	Stop	2
47	SA 8230-09650	Stop	2
48	SA 9511-22035	O-ring more	2
49	SA 9511-22095	O-ring more	1
50	SA 9511-22145	O-ring more	4
51	SA 9511-12008	O-ring more	16
52	SA 9511-12011	O-ring more	8
53	SA 9511-12024	O-ring more	4
54	SA 9511-12018	O-ring more	2
55	SA 8230-26900	Seal more	1
56	SA 9566-10180	Ring	2
57	SA 9566-20350	Ring	2
58	SA 8230-25620	Nut	2
59	SA 9111-12000	Nut more	2
60	SA 8230-25980	Ring	2
61	SA 8230-26430	Plate	2
62	SA 7223-00660	Spring Pin	4
63	SA 8230-25450	Eye Bolt	2
64	SA 8230-26780	Bolt	2
65	SA 8230-09700	Bolt	2
100	SA 8148-13080	Sealing Kit more	1

Model	Nominal displacement (ml/r)	Pressure(MPa)		Speed(r/min)			Volumetric efficiency (≥%)	L1	L	A	d	D		Weight (kg)
		Rated	Max	Min	Rated	Max
												Intet	Outlet
CBN-F520-BF**	20	20	25	600	2500	3000	92	66.5	134	48	65	25	20	5.1
CBN-F525-BF**	25							68.5	138					5.3
CBN-F532-BF**	32						93	69	139			30		5.6
CBN-F540-BF**	40							72	145	51	76	35		5.9
CBN-F550-BF**	50							76	153				25	6.3
CBN-F563-BF**	63							81.5	164					6.8
